Aluminum LED Wall Light Pure White Surface Color With Unique Lighting Effect



Aluminum LED Wall Light Pure White Surface Color With Unique Lighting Effect





Quick Details



1. Power:1 x 3W

2. Voltage:24VDC,AC100V-240V

3. Size:Φ79mm x H32MM,79 x 79 x H32mm

4. Lighting Way:Side-emitting

5. Light Source:High Power LED

6. Housing:Die-casting aluminum

7. Surface Color:Silvery,Pure White





Technical Datas



Model No.	AL-WRS-001
Input Voltage	24V,120V,240V
Power	3W
Light Dimension	D79mm x H32m
Sleeve Dimension	D71mm x H77mm
Color	R/G/B/Y/Amber/W/CW/WW
Color Temperature	2700K~6500K
LED Chip	CREE 3W high power LED
LED Qty	1pcs
Beam Angle	80°
Dimmable	YES
IP Grade	IP67
Carton Package Dimension	29 x 20 x 29CM
Carton Package Qty	18pcs
Carton Package Weight	6kg
Certification	CE,RoHS
Warranty	2/3years





Model Number Explain



Model No.	Color	Beam Angle
AL-WRS-002	Single Color	80°
AL-WRS-005	RGB 3in1	80°
AL-WRS-005M	RGB 3in1 with DMX512	80°
AL-WRS-007	RGBW 4in1	80°





Dimension







Material & Manufacturing Technique



Housing:12# Die-casting aluminum

Light Source:Emitter type power LED

Driver:Low & High input-coltage driver inside

LED:High power LED

Loading capacity:Exert force area of Φ10=1330Kgs

Applicaation environment: -20℃-40℃

Power cable: H05RN-F 3x1.0mm² L=0.3M (High Voltage)

                        H05RN-F 2x1.0mm² L=0.3M (Low Voltage)

Mounting Sleeve:035PVC





Competitive Advantage



1. Die-casting aluminum light housing,good heat-dissipation,long lifespan.

2. Appearance diversification-Round & Square shape optional;Silver & Pure White & RAL9023

    optional,meet diversified lighting design style.

3. Adymmetrical and side-emitting,beautiful and unique lighting effect.

4. Wall recessed & Ceiling installation,different installation different lighting style.

5.CE & RoHS,Two years warranty,10 years manufacturing and exported experience,Professional

   quality control and best after-sales service.
