Underwater Led Lights For Ponds With 316 Stainless Steel Housing And Bracket


Underwater Light With 316 Stainless Steel Housing And Bracket For Pond Lighting


Parameters




Features

1.Source: Epistar/Cree/Osram high power LED, bright and uniform light.
2.ROHS materials compliant, environmental friendly.
3.Opto LED symbiosis for peak lm.
4.316# stainless steel.
5.IP68, 100% waterproof. Can be put in the water.
6.8mm Tempered glass, able to bear huge pressure.
7.Durable Cable PG-11. With embered box and screw for easy installation.
8.CE, ROHS, IP68 approved


Photoes




Material & Manufacturing Technique

Housing:Molding shaped stainless steel sus316#.
Front cover:stainless steel sus316#.
Bracket:stainless steel sus316#.
Glass:Tempered glass,T=5mm
Lens:Optional lens,efficiency ≥ 85%
Cable gland:IP68 PG-11 copper with nickel-coated.
Seal:Molding shaped silicone seal under the front cover
        Silicone gule among the LED,lens and PCB.
LED:CREE COB LED
PCB:Excellent heat conductivity aluminum,coefficient of heat conductivity≥2.0w/mk
Driver:Constant current output
           Single color LED=2-circuit output
           RGB 3in1 LED=6-circuit output
Applicaation environment:Temperature of water between -20℃-40℃ less than 1m depth
Power cable:H07RN-F 2x1.0m² L=2m(for single color)
                      H07RN-F 4x0.75m² L=2m(for RGB)


Model Number Infos




Competitive Advantage

1) Whole lamp is made of 316 / 304 Stainless Steel,3W Weight = 1.5Kg,6W Weight = 2.13Kg,
   12W Weight = 3.1Kg,high level quality LED underwaterlight.
2) With 304/316 SS tripod,lamp lighting beam angle can be adjustbale.
3) High power CREE & Osram LED,W/WW/R/G/B/Y/RGB 3in1 color optional,meet diversified lighting color
    Change.
4) H07RN-F trong power cable length can be customzied.
5) Professional 10 years manufacturing and exporting experience,keep good quality control and good
    after-sales service.


Warm Tip & Warning

1) The Φ90mm Φ130mm Φ158mm 3W 6W 12W LED Underwater Lights has to be lighted underwater.
    Pls don't light it more than 15 minutes out of water!
2) The LED underwater light is 12V / 24V low voltage,pls don't connect it to 220V / 240V high voltage,this
    will burn the LED underwater light.
3) The best height for this LED underwater light lighting is within 1M.
4) The power cable length can be customized.
5) This LED underwater light has very lighting effect for fountain lighting project.


Tag

LED underwater lights,LED underwater spotlights,LED underwater lights with bracket,316 stainless steel
underwater lights,LED swimming pool lights,LED pond lights,IP68 underwater lights


More Photoes


LED Swimming Pool Lights

LED Underwater Pool Lights

Underwater Led Lights For Ponds With 316 Stainless Steel Housing And Bracket Images
